Diktator is a two channel - clean, transparent preamp & overdrive / distortion that operate independently.

FEATURES:
DETONATOR CHANNEL
From light crunch - fat overdrive - up to tight distortion. Two toggle switches allow different tonal & gain shapes, any desired frequency is easily cut or boosted

Diktator’s eyes - flash to show level of the drive’s dynamic response

Level - controls the output volume level

Bass - controls the bass frequencies of the distortion. Can cut or boost the bass frequencies as an active tone control.

Treble - controls the treble of the distortion section. Cut or boost the upper frequencies as an active tone control

Drive - controls the amount of distortion - from slightly gritty clean to warm overdrive, all the way to distortion

Hard/Soft - Switch between vintage & modern distortion (more overall gain)

Dark/Bright
Switches between two types of clipping diode for brighter, crunchy and darker, more mellow tone

FUSE CHANNEL
Alone it's a transparent preamp to refine the original tone, sounds bigger & pushes the amplifier into natural overdrive. If with the detonator channel, it hits your amp hard & is an excellent booster for lead parts and solos

Boost - controls the gain of the preamp from unity gain to a fairly hot signal (up to about 30dB of boost).

Diktator utilizes improved power supply filtering circuitry, RF rejection filter, smart PCB routing, no-wire design, audiophile quality components & true bypass switching


TECHNICAL SPECIFICATIONS:
Power Input Voltage: 9 - 18V
Power input connector: 2.1mm barrel connector (Negative tip)
Power Consumption: 13mA
Size: 4.4” x 3.5”
